POWERCOM RAPTOR 800VA UPS USB

תיאור מוצר

UPS
Model	RPT-600AP	RPT-800AP	RPT-1000AP	RPT-1025AP	RPT-1500AP	RPT-2000AP
Model	RPT-600A	RPT-800A	RPT-1000A	RPT-1025AP	RPT-1500AP	RPT-2000AP
Capacity(VA)	600 VA	800 VA	1000 VA	1025 VA	1500 VA	2000 VA
Capacity(Watts)	360 W	480 W	600 W	615 W	900 W	1200 W
Form	Tower Type
INPUT
Nominal Voltage	100 / 110 / 120VAC or 220 / 230 / 240VAC
Voltage Range	75 – 150VAC or 165 – 300VAC
Frequency Range	50Hz / 60Hz(Auto Sensing)
OUTPUT
Voltage	100 / 110 / 120VAC or 220 / 230 / 240VAC
Frequency Range	50 / 60 Hz ± 0.25HZ
Transfer Time(ms)	2 – 4 (Typical)
Waveform	Simulated Sine Wave
BATTERY
RPT Model	600VA	800VA	1000VA	1025VA	1500VA	2000VA
Type & Number	12V7Ah x 1	12V7.2Ah x 1	12V9Ah x 1	12V7Ah x 2	12V7.2Ah x 2	12V9Ah x 2
Recharge Time	3 ~ 4 hours to 90% capacity
GENERAL
RPT Model	600VA	800VA	1000VA	1025VA	1500VA	2000VA
Net Weight(Kgs)	4.3	4.8	5.4	8.5	10.1	11.1
Gross Weight(Kgs)	4.8	5.3	5.9	9.7	11.3	12.3
Dimension(W.D.H)	100 * 278 * 143			147 * 360 * 164
Indicator	LED indicator			LED or LCD
PROTECTION
Full Protection	Overload, Fuse, Tele-Communication
PHYSICAL
Dimension (WxDxH)(mm)	100 x 278 x 143			147 x 360 x 164
Weight (kgs)	4.3	4.8	5.4	8.5	10.1	11.1
Shipping Dimension (mm)	147 x 329 x 227			233 x 449 x 277
Shipping Weight (kgs)	4.8	5.3	5.9	9.7	11.3	12.3
ALARM
Overload	Continuous Beeping
Battery Mode	Beep every 2 seconds
Low Battery	Beep every 0.5 second
MANAGEMENT
Interface	Usb Port / Serial Port / Software
ENVIRONMENT
Humidity	0 ~ 95% RH at 0 ~ 40°C(Non-condensing)
Audible Noise	Less than 40 dB
